HENTG Power Single Phase 50kVA Pad Mounted Distribution Transformer

Designed for residential and commercial power applications with 50/60Hz frequency requirements.

Key Features

CE Certified & Global Standard Compliance: Meets EU CE directives with rigorous safety and EMC testing for worry-free operation and global market access.
Durable Pad-Mounted Design: Fully enclosed protection against harsh environments including rain, dust, and salt spray. Ideal for outdoor, community, and agricultural applications.
Easy Installation: Eliminates need for poles with direct concrete base placement, saving space and reducing installation costs.
Stable Performance: Provides precise voltage output for 50kVA to 100kVA power range applications, protecting home appliances and commercial equipment.
Efficient Operation: High-quality silicon steel construction delivers low losses, low noise, and high efficiency for reliable community, business, and farm power solutions.

Technical Specifications

Capacity (KVA)	HV	Tapping Range	LV	No-load Loss (W)	Load Loss (W)	Dimension (mm)	Efficiency (%)
15	2400-34500	±2X2.5%	110-690	60-150	330-1150	610-740 (W) * 740-960 (D) * 840 (H)	98.82-99.49
25	2400-34500	±2X2.5%	110-690	60-150	330-1150	610-740 (W) * 740-960 (D) * 840 (H)	98.95
37.5	2400-34500	±2X2.5%	110-690	60-150	330-1150	610-740 (W) * 740-960 (D) * 840 (H)	99.05
50	2400-34500	±2X2.5%	110-690	60-150	330-1150	610-740 (W) * 740-960 (D) * 840 (H)	99.11
75	2400-34500	±2X2.5%	110-690	60-150	330-1150	610-740 (W) * 740-960 (D) * 840 (H)	99.19
100	2400-34500	±2X2.5%	110-690	60-150	330-1150	610-740 (W) * 740-960 (D) * 840 (H)	99.25
